Varitrans Compactline

The operable glass partition system with bespoke curved profiles offers numerous equipment options.

  • Super-stable design (steel-aluminum construction)
  • Sound reduction ratings up to Rw 59 dB with optimized profiles and seals
  • Low VOC emissions sets new standards
  • The combination with Variflex glass elements offers many design options

Flexible room partitioning with transparent benefits

Varitrans glass elements from DORMA Hppe provide a clear view of the e···...

Operating convenience from manual to fully automatic

There are two operating systems available to suit your effort-saving r···...

Sound advice right from the initial planning phase

Whether for a new building, a conversion or a refurb, the decision in ···...

Features

  • Movable glass wall system with bespoke curved profiles
  • Multifunctional configuration flexibility: straight line, angled or polygonal layouts all possible
  • Manual and effortless fully automatic control
  • Low running noise thanks to precision-engineered tracks of aluminium
  • Sustainability included: Covered by environmental product declaration (EPD) to ISO 14025 and EN 15804

Technical Data

  • Clear height: manual max. 3,500 mm; fully automatic (ComfortDrive) max. 4,000 mm
  • Element widths: max. 1,300 mm
  • Glass: 10 and 12 mm TSG, 11.5 mm LSG
  • Wide range of elements: Full wall, corner, angled elements, wall flaps, fixed full-height doors, operable pass doors
