Variflex 100
Offering very high sound reduction ratings this sturdy partition system will ensure parallel events can take place without cross-interference.
Features
- Super-stable design (steel-aluminium construction)
- Low specific weights per unit area for easy handling and obvious structural advantages.
- Sound reduction ratings up to Rw 59 dB with optimised profiles and seals.
- Variflex and Variflex Glass can be combined for a partition that offers both sound insulation and transparency
- Manual, semi-automatic and fully automatic control
- Smoke control certificate to EN 1634-3 as standard
- Sustainability included: Covered by environmental product declaration (EPD) to ISO 14025 and EN 15804
Surface Finishes
Standard
- Classic Collection: Melamine and HPL (high-pressure laminate)
Premium
- Design Collection
- Functional Collection
- Other surface finishes
Technical Data
- Clear passage height: max. 14,500 mm
- Panel width: max. 1,250 mm
- Sound insulation
Variflex 100
| Rw in dB | 39 | 46 | 49 | 52 | 55 | 57 | 59 |
|---|---|---|---|---|---|---|---|
| Weight kg/m2 | 30 | 31 | 40 | 40 | 48 | 48 | 56 |
Variflex Glass
| Rw in dB | 47 | 50 | 52 |
|---|---|---|---|
| Weight kg/m2 | 49 | 45 | 56 |
